Pipe & Tubes

Pipes and Tubes are essential elements in modern industrial, commercial, and mechanical applications, designed for superior strength, durability, and precision engineering. They are widely used for transporting liquids, gases, and chemicals, as well as in structural frameworks and mechanical components. Manufactured in a wide variety of materials including stainless steel, carbon steel, alloy steel, Inconel, Monel, Hastelloy, and aluminium, our pipes and tubes are designed to withstand high pressure, extreme temperatures, and corrosive environments.

Our comprehensive range of pipes and tubes comes in multiple diameters, wall thicknesses, lengths, and grades, ensuring they meet diverse industrial requirements. These products are engineered and tested to deliver superior mechanical strength, tensile resistance, impact resistance, and corrosion protection. Whether for oil and gas pipelines, chemical processing plants, pharmaceutical equipment, marine applications, or automotive and aerospace components, our pipes and tubes provide reliable performance, long-term durability, and consistent quality.

Available Grades of Round Bar

Material Standard Available Grades
1 2 3 4 5 6 7 8 9 10
Stainless Steel ASTM A312 / A213 304 304L 304H 309 310 310S 316 316L 316Ti 317L
321 321H 347 347H 410 446 904L
Duplex / Super Duplex ASTM A790 / A928 Duplex S31803 / S32205 Super Duplex S32750 / S32760
Nickel Alloys ASTM B161 / B163 Nickel 200 Nickel 201 Inconel 600 Inconel 601 Inconel 625 Inconel 718 Incoloy 800 Incoloy 800HT Incoloy 825
Alloy Steel ASTM A335 / A213 P5 P9 P11 P12 P22 P91 P92
Titanium ASTM B338 Gr 1 Gr 2 Gr 5 Gr 9
Carbon Steel ASTM A106 / A53 / API 5L Seamless ERW SAW LSAW HSAW API 5L
Copper Nickel ASTM B466 / B467 CuNi 70/30 CuNi 90/10
Other Alloys - SMO 254 Alloy 28 253 MA (S30815) Alloy 20 Hastelloy Aluminium

Titanium

Titanium pipes and tubes are high-performance products recognized for their exceptional strength-to-weight ratio, corrosion resistance, and thermal stability. These materials are widely used in industries such as aerospace, marine, chemical processing, pharmaceuticals, and medical engineering. Titanium tubes and pipes are ideal for transporting corrosive fluids, handling high-pressure systems, and constructing lightweight yet durable structural frameworks. Their excellent mechanical properties and long-term reliability make them a preferred choice for demanding and high-performance projects.

  • Exceptional corrosion resistance in seawater, chemical, and acidic environments

  • High strength-to-weight ratio for lightweight and robust piping systems

  • Excellent thermal and pressure resistance for extreme operating conditions

  • Available in various grades such as Grade 2, Grade 5, and Grade 9 to meet specific application needs

  • Superior weldability and fabrication properties for complex engineering designs

  • Precision dimensional accuracy and high-quality surface finish for safe and reliable installations

  • Widely used in aerospace fuel lines, marine piping systems, chemical processing plants, and medical and pharmaceutical equipment


Hastelloy

Hastelloy pipes and tubes are high-performance nickel-based alloy products known for their outstanding corrosion resistance, oxidation resistance, and mechanical strength even in the most demanding environments. These products are widely used in chemical processing, marine, pharmaceutical, and petrochemical industries where exposure to strong acids and oxidizing conditions is common. Hastelloy pipes and tubes offer reliable performance for transporting corrosive fluids and gases, and are ideal for heat exchangers, condensers, and pressure vessels.

  • Superior corrosion resistance in oxidizing and reducing environments

  • Excellent mechanical strength and thermal stability under high pressure and temperature

  • Exceptional weldability and fabricability for various industrial applications

  • Available in different grades including C22, C276, and B2

  • Resistant to pitting, crevice corrosion, and stress corrosion cracking

  • Smooth inner surface finish for improved fluid flow and reduced contamination

  • Suitable for heat exchangers, chemical process equipment, and offshore applications


Monel

Monel pipes and tubes are high-quality nickel-copper alloy products known for their exceptional corrosion resistance, strength, and durability in harsh and demanding environments. These pipes and tubes are widely used in marine engineering, chemical processing, oil & gas, and aerospace industries due to their ability to withstand exposure to seawater, acids, and alkalis. Monel pipes and tubes ensure reliable performance in applications such as heat exchangers, condensers, and fluid transfer systems where high strength and corrosion resistance are essential.

  • Excellent corrosion resistance in seawater, acids, and alkaline environments

  • High mechanical strength and durability under extreme temperatures and pressures

  • Superior resistance to stress corrosion cracking, pitting, and erosion

  • Available in multiple grades such as Monel 400 and Monel K500

  • Excellent weldability and formability for complex fabrication

  • Smooth inner surface finish ensuring optimal fluid flow and minimal contamination

  • Ideal for heat exchangers, condensers, chemical process equipment, and marine piping systems


Inconel

Inconel pipes and tubes are high-performance nickel-chromium-based alloy products designed to deliver superior oxidation resistance, corrosion resistance, and mechanical strength under extreme conditions. These pipes and tubes are engineered for applications involving high temperatures, pressure, and oxidizing environments, making them ideal for use in aerospace, power generation, chemical processing, and marine industries. Inconel pipes and tubes are widely used in heat exchangers, boilers, condensers, and high-temperature fluid transfer systems where long-term durability and performance are critical.

  • Exceptional oxidation and corrosion resistance at high temperatures and pressures

  • Retains mechanical strength and stability in extreme thermal environments

  • Excellent resistance to creep, pitting, and stress corrosion cracking

  • Available in various grades such as Inconel 600, 625, 718, and X750

  • Superior weldability and fabricability for seamless and welded pipe production

  • Smooth internal surface finish for enhanced flow efficiency and reduced contamination

  • Ideal for heat exchangers, boilers, chemical process equipment, and high-temperature piping systems


Stainless Steel

Stainless steel pipes and tubes are high-quality alloy products known for their exceptional corrosion resistance, strength, and durability across a wide range of environments. Manufactured with precision, these pipes and tubes are ideal for use in chemical processing, food and beverage, oil & gas, pharmaceutical, and construction industries. Stainless steel pipes and tubes provide excellent resistance to oxidation, high pressure, and temperature variations, making them suitable for both structural and fluid transport applications such as heat exchangers, condensers, and industrial piping systems.

  • Outstanding corrosion resistance in acidic, alkaline, and marine environments

  • Excellent mechanical strength and durability under high pressure and temperature

  • Superior resistance to oxidation and scaling at elevated temperatures

  • Available in various grades such as 304, 304L, 316, 316L, 321, and 347

  • Excellent weldability and formability for diverse industrial applications

  • Smooth inner surface finish ensures better flow and prevents contamination

  • Ideal for heat exchangers, boilers, process piping, and structural applications


Aluminium

Aluminium pipes and tubes are lightweight, corrosion-resistant, and highly versatile products offering an excellent strength-to-weight ratio, thermal conductivity, and formability. These pipes and tubes are extensively used in aerospace, automotive, construction, marine, and electrical industries for their superior performance in harsh and demanding environments. Aluminium pipes and tubes are ideal for applications requiring efficient heat transfer, structural integrity, and lightweight durability — such as condensers, radiators, hydraulic systems, and architectural frameworks.

  • Exceptional strength-to-weight ratio for lightweight yet durable performance

  • Excellent corrosion resistance in marine and outdoor environments

  • High thermal and electrical conductivity suitable for heat exchangers and electrical systems

  • Available in various grades such as 1100, 5052, 6061, 6082, 7075, and 8011

  • Superior formability, weldability, and machinability for custom fabrication

  • Smooth internal and external surface finish ensuring efficient flow and aesthetic appeal

  • Ideal for heat exchangers, hydraulic systems, automotive exhausts, and structural frameworks



Chemical Composition (Standard Pipe Grades)

Material Grade C (Max %) Mn (Max %) P (Max %) S (Max %) Si (Max %) Cr (%) Ni (%) Mo (%)
SS 304 0.082.000.0450.0300.75 18.0 - 20.08.0 - 10.5-
SS 316 0.082.000.0450.0300.75 16.0 - 18.010.0 - 14.02.0 - 3.0
SS 316L 0.032.000.0450.0300.75 16.0 - 18.010.0 - 14.02.0 - 3.0
Carbon Steel (A106 Gr. B) 0.300.29 - 1.060.0350.0350.10 0.40 (Max)0.40 (Max)0.15 (Max)

Mechanical Properties (Pipes & Tubes)

Material Grade Tensile Strength (Min) Yield Strength (Min) Elongation (Min %) Hardness (Max)
SS 304 / 304L 515 MPa 205 MPa 35% 90 HRB
SS 316 / 316L 515 MPa 205 MPa 35% 90 HRB
Carbon Steel (A106 Gr. B) 415 MPa 240 MPa 30% -
Alloy Steel (P11) 415 MPa 205 MPa 30% 163 HB

Pipe Dimensions & Weight Chart (kg/m)

NB Size OD (mm) Schedule 10 Schedule 40 Schedule 80
Thk (mm) Wt (kg/m) Thk (mm) Wt (kg/m) Thk (mm) Wt (kg/m)
1/2" 21.34 2.111.00 2.771.27 3.731.62
3/4" 26.67 2.111.28 2.871.69 3.912.20
1" 33.40 2.772.09 3.382.50 4.553.24
1 1/2" 48.26 2.773.11 3.684.05 5.085.41
2" 60.33 2.773.93 3.915.44 5.547.48
3" 88.90 3.056.46 5.4911.29 7.6215.27
4" 114.30 3.058.37 6.0216.07 8.5622.32
6" 168.28 3.4013.82 7.1128.26 10.9742.56
8" 219.08 3.7619.97 8.1842.55 12.7064.64
